Our new control unit Black.4 is the new, slim reference desing for most light systems. It delivers fast and brillinat results for all ranges of modelling and was massively improved in all areas of operation. With the four functions: strobe, beacon/ACL, navigation and spotlights - all controllable over one servo channel - it is perfectly usable for nearly each aircraft.
New in BLACK series
Dynamic nicer, faster and sharper defined light effects
Variety more light patterns preprogrammed
Dimensions reduced size and weight, polarity correct output sockets
Safety basic shortcut protection, cut off and automatic restore
Power up to 5 ampere per channel, 8 ampere combined
Battery deep discharge protection for connected Lipos
Master-Slave activation by the receiver power
Scale soft transition as special function selectable
Sport navigation with strobe function for many sport applications
Future new hardware platform allows future updates
Special Function
Slow Signals a soft transition simulates a soft glow-on and glow-off like an old glow bulb or simulates a rotating beacon effect of slow blinking functions.
Fast Signals during strobe sequences a basic level of around 20% power is given to the light. With these function a strong strobe light can be operated as navigation light AND at the same time be a strobe signal. Perfectly usable on sport models: one light, two functions
Technical data
receiver side 4.8-9.6V
weight ~8g, without wire
dimension 50x35x6mm
load per channel 5A to 16V (>6A peak)
total load up to 8A
galvanically isolated circuits
operation without RC possible
15+1 classic effects with variable speed
15+1 modern effects with variable speed
15+1 special effects with variable speed
soft transition programmable
sport-nav mode programmable
short circuit protection
deep discharge protection
reverse polarity protection
simple servo output for dropouts, switches or valves
including quick-snap mountig brackets
